Corrugated Sidewall Conveyor

A Corrugated Sidewall Conveyor is a specialized belt conveyor system designed to transport bulk materials at steep angles, even vertically. It features a belt with corrugated rubber sidewalls and cleats, which prevent materials from slipping or falling off during inclined transport. This unique design allows for space-saving vertical or steep-incline conveying in industries such as mining, agriculture, cement, recycling, and construction.

The corrugated sidewalls are flexible yet strong, forming a continuous barrier along the sides of the belt. Cleats are securely attached between the sidewalls to support and carry materials upward, maintaining product stability and preventing rollback. The belt is made from high-strength rubber or synthetic materials, offering excellent wear resistance and durability in harsh environments.

Corrugated sidewall conveyors are ideal for conveying bulk materials like coal, sand, grain, ores, and fertilizers, especially in areas with limited horizontal space. They eliminate the need for multiple transfer points, reducing material loss, dust generation, and equipment wear.

Easy to install and maintain, this conveyor system increases efficiency, minimizes spillage, and ensures a reliable material flow in complex layouts. It is an excellent solution for operations that require high-capacity transport in compact or vertical configurations.

High-Incline Corrugated Sidewall Belt Conveyor

View More

What Are The Three Types Of Conveyors?

Conveyors are essential equipment in material handling systems, used to transport products efficiently across various industries. The three most common types of conveyors are Belt Conveyors, Roller Conveyors, and Chain Conveyors. Each type serves specific purposes and is selected based on the material, application, and environmental conditions.

Belt Conveyors are the most widely used type. They consist of a continuous belt made of rubber, PVC, or other synthetic materials, stretched over pulleys and driven by a motor. Belt conveyors are ideal for transporting light to medium-weight items over short or long distances. They offer smooth and quiet operation, making them suitable for industries like packaging, warehousing, agriculture, and food processing.

Roller Conveyors use a series of cylindrical rollers to move items. These can be gravity-powered or motor-driven, and they are ideal for transporting flat-bottomed items such as boxes, pallets, and totes. Roller conveyors are commonly used in distribution centers, assembly lines, and sorting systems due to their simplicity, low maintenance, and adaptability.

Chain Conveyors use chains to carry heavy loads, making them ideal for harsh environments and heavy-duty applications such as automotive, steel, and industrial manufacturing. The chain provides positive drive, ensuring consistent movement even under tough conditions.

Each conveyor type offers unique advantages, and the right choice depends on the load, speed, direction, and space requirements of the specific operation.

What Are Conveyor Rollers Called?

Conveyor Rollers are commonly referred to by several names depending on their specific function and design within a conveyor system. Some of the most widely used terms include idler rollers, carry rollers, return rollers, impact rollers, and guide rollers. Each type plays a unique role in ensuring the efficient movement and support of the conveyor belt and the materials it transports.

Idler Rollers are the general term for rollers that support the conveyor belt and help maintain its alignment without driving it. These can be found on both the carrying and return sides of the conveyor.

Carry Rollers are positioned on the top side of the conveyor and support the loaded belt as it moves material from one point to another.

Return Rollers are placed underneath the conveyor to support the empty belt on its return journey after unloading the material.

Impact Rollers are used at loading points where materials are dropped onto the belt. They are designed with rubber rings or sleeves to absorb shock and protect the belt from damage.

Guide Rollers help maintain proper belt tracking and prevent misalignment, especially in systems with curves or elevation changes.

Made from durable materials like steel, stainless steel, or high-impact plastic, conveyor rollers are critical to system performance, reducing wear and ensuring smooth, consistent movement.
